4-72
Pn51E Deviation counter overflow warning level (Position)
Setting
range
0 to 100 Unit % Default
setting
0 Restart
power?
No
• Set the deviation counter overflow warning detection level using the ratio (%) for Pn505 (deviation
counter overflow level).
• When the deviation counter residual pulses exceed the set value, a deviation counter overflow warn-
ing (A.90) will occur.
• When the set value is 0, the deviation counter overflow warning will not be detected.
Note This new parameter is supported by Servo Drivers with software version “r.0037.”
H Other Parameters (From Pn600)
Pn600 Regeneration resistor capacity
Setting
range
0 to Unit
type
Unit x 10 W Default
setting
0 Restart
power?
No
• If using an External Regeneration Resistor or External Regeneration Resistance Unit, set the regen-
eration absorption amount. Set the regeneration absorption amount for when the temperature rises
above 120°C, not the nominal amount. (Refer to Regenerative Energy Absorption Using External Re-
generation Resistance for details.)
• Perform Un00A (regeneration load monitor) calculations, and A.92 (regeneration overload warning)
and A.32 (regeneration overload alarm) based on the Pn600 setting.
Note If an External Regeneration Resistor or External Regeneration Resistance Unit is not connected,
set Pn600 to 0.
Pn601 Not used.
Setting
range
--- Unit --- Default
setting
0 Restart
power?
No
Note Do not change the setting.
Operation Chapter 4
To Next Page
