6-24
Parame-
ter No.
Restart
power?
Setting
range
UnitDefault
setting
Explanation (See note 1.)Parameter
name
Parame-
ter No.
Restart
power?
Setting
range
UnitDefault
setting
Explanation (See note 2.)Set-
ting
Name
Digit
No.
Parameter
name
Pn50A Input signal
selection 1
0 Input signal
allocation
mode
0 Sets the sequence input signal
allocation to the same as
R88D-UT.
8100 --- --- Ye s
1 User-defined sequence input
signal allocation
1 RUN signal
(RUN
0 Allocated to CN1, pin 40: Valid
at low input.
command)
input
1 Allocated to CN1, pin 41: Valid
at low input
allocation
2 Allocated to CN1, pin 42: Valid
at low input
3 Allocated to CN1, pin 43: Valid
at low input
4 Allocated to CN1, pin 44: Valid
at low input
5 Allocated to CN1, pin 45: Valid
at low input
6 Allocated to CN1, pin 46: Valid
at low input
7 Always enabled.
8 Always disabled.
9 Allocated to CN1, pin 40: Valid
at high output
A Allocated to CN1, pin 41: Valid
at high output
b Allocated to CN1, pin 42: Valid
at high output
C Allocated to CN1, pin 43: Valid
at high output
d Allocated to CN1, pin 44: Valid
at high output
E Allocated to CN1, pin 45: Valid
at high output
F Allocated to CN1, pin 46: Valid
at high output
2 MING signal
input
terminal
allocation
0 to F Same as Pn50A.1.
MING (gain reduction) signal
allocation
3 POT signal
input
terminal
allocation
0 to F Same as Pn50A.1
POT (forward drive prohibited)
signal allocation
Pn50b Input signal
selection 2
0 NOT signal
input
terminal
allocation
0 to F Same as Pn50A.1.
NOT (reverse drive prohibited)
signal allocation
6548 --- --- Ye s
1 RESET
signal input
terminal
allocation
0 to F Same as Pn50A.1.
RESET (alarm reset) signal
allocation
2 PCL signal
input
terminal
allocation
0 to F Same as Pn50A.1.
PCL (forward rotation current
limit) signal allocation
3 NCL signa
input
terminal
allocation
0 to F Same as Pn50A.1.
NCL (reverse rotation current
limit) allocation
Appendix Chapter 6
