2-37
H 3,000-r/min Servomotors without a Brake
D 200 V AC: 1 kW/1.5 kW/2 kW/3 kW/4.0 kW/5.0 kW
R88M-W1K030H(-S2)/-W1K5030H(-S2)/-W2K030H(-S2)/-W3K030H(-S2)/
-W4K030H(-S2)/-W5K030H(-S2) [Incremental]
R88M-W1K030T(-S2)/-W1K5030T(-S2)/-W2K030T(-S2)/-W3K030T(-S2)/
-W4K030T(-S2)/-W5K030T(-S2) [Absolute]
Effective depth: 16
Four, Z dia.
D2 dia.
S dia.
Dimensions of shaft end with key (-S2)
D3 dia.
D1 dia.
Model
Dimensions (mm)
LL LR KB1 KB2 KL1 KL2 C D1 D2 D3 F G Z S QK
R88M-W1K030j-j
148
45
76 128
96 88 100 115 95h7 130 3 10 7 24h6 32
R88M-W1K530j-j
175 102 154
R88M-W2K030j-j
198 125 177
R88M-W3K030j-j
199
63
124 178
114 88 130 145 110h7 165 6 12 9 28h6 50
R88M-W4K030j-j
236 161 215
R88M-W5K030j-j
276 201 255
Note The external dimensions are the same for IP67 (waterproof) models (-Oj).
Standard Models and Specifications
Chapter 2
