Omron OMNUC R88D-WT15HF User Manual

2-58
Dimensions (mm)
Model
E1 E3 F G S T Z IE
Key dimensions
QK b h t1
57 20 3 12 35 55 12 – 47 10 8 5
450 W
1/5
R88M-W45015T-jG05BJ
57 20 3 12 35 55 12 – 47 10 8 5
50
1/9
R88M-W45015T-jG09BJ
77 33 5 15 50 75 12 137 65 14 9 5.5 1/20
R88M-W45015T-jG20BJ
77 33 5 15 50 75 12 137 65 14 9 5.5 1/29
R88M-W45015T-jG29BJ
77 33 5 15 50 75 12 137 65 14 9 5.5 1/45
R88M-W45015T-jG45BJ
57 20 3 12 35 55 12 – 47 10 8 5
850 W
1/5
R88M-W85015T-jG05BJ
57 20 3 12 35 55 12 – 47 10 8 5
850
1/9
R88M-W85015T-jG09BJ
77 33 5 15 50 75 12 137 65 14 9 5.5 1/20
R88M-W85015T-jG20BJ
77 33 5 15 50 75 12 137 65 14 9 5.5 1/29
R88M-W85015T-jG29BJ
92 38 5 18 60 90 14 171 78 18 11 7 1/45
R88M-W85015T-jG45BJ
77 33 5 15 50 75 12 137 65 14 9 5.5
1.3 kW
1/5
R88M-W1K315T-jG05BJ
77 33 5 15 50 75 12 137 65 14 9 5.5
3
1/9
R88M-W1K315T-jG09BJ
77 33 5 15 50 75 12 137 65 14 9 5.5 1/20
R88M-W1K315T-jG20BJ
92 38 5 18 60 90 14 171 78 18 11 7 1/29
R88M-W1K315T-jG29BJ
92 38 5 18 60 90 14 171 78 18 11 7 1/45
R88M-W1K315T-jG45BJ
77 33 5 15 50 75 12 137 65 14 9 5.5
1.8 kW
1/5
R88M-W1K815T-jG05BJ
77 33 5 15 50 75 12 137 65 14 9 5.5
8
1/9
R88M-W1K815T-jG09BJ
92 38 5 18 60 90 14 171 78 18 11 7 1/20
R88M-W1K815T-jG20BJ
92 38 5 18 60 90 14 171 78 18 11 7 1/29
R88M-W1K815T-jG29BJ
92 38 5 18 60 90 14 171 78 18 11 7
2.9 kW
1/5
R88M-W2K915T-jG05BJ
92 38 5 18 60 90 14 171 78 18 11 7
9
1/9
R88M-W2K915T-jG09BJ
92 38 5 18 60 90 14 171 78 18 11 7 1/20
R88M-W2K915T-jG20BJ
92 38 5 18 60 90 14 171 78 18 11 7
4.4 kW
1/5
R88M-W4K415T-jG05BJ
92 38 5 18 60 90 14 171 78 18 11 7 1/9
R88M-W4K415T-jG09BJ
Diagram 2
Key dimensions
Four, Z dia.
D5 dia.
Sh6 dia.
D1 dia.
D2 dia.
D4 dia.
D3h7 dia.
jC2
Standard Models and Specifications
Chapter 2
