4-170
4-4 Communication Function
4
Functions
0016h OL (overload warning) R
1: ON
0: OFF
0017h OD (excessive PID deviation) R
1: ON
0: OFF
0018h AL (alarm signal) R
1: ON
0: OFF
0019h
FA3 (set-frequency-only arrival
signal)
R
1: ON
0: OFF
001Ah OTQ (overtorque) R
1: ON
0: OFF
001Bh
IP (during momentary power
interruption)
R
1: ON
0: OFF
001Ch UV (during undervoltage) R
1: ON
0: OFF
001Dh TRQ (during torque limit) R
1: ON
0: OFF
001Eh RNT (RUN time exceeded) R
1: ON
0: OFF
001Fh ONT (ON time exceeded) R
1: ON
0: OFF
0020h THM (thermal warning) R
1: ON
0: OFF
0021h Not used
0022h Not used
0023h Not used
0024h Not used
0025h Not used
0026h BRK (brake release) R
1: ON
0: OFF
0027h BER (brake error) R
1: ON
0: OFF
0028h ZS (0 Hz signal) R
1: ON
0: OFF
0029h DSE (excessive speed deviation) R
1: ON
0: OFF
002Ah POK (position ready) R
1: ON
0: OFF
002Bh FA4 (set frequency exceeded 2) R
1: ON
0: OFF
002Ch FA5 (set frequency only 2) R
1: ON
0: OFF
002Dh OL2 (overload warning signal 2) R
1: ON
0: OFF
Coil No. Item R/W Description
*1. When either the control circuit terminal block or the coil is turned on, these settings are ON.
The control circuit terminal block has the priority for the multi-function input terminals.
If the master cannot reset the coil ON status because of communication disconnection, turn the control
circuit terminal block from ON to OFF to turn off the coil.
*2. The communications error is retained until a fault reset is input. (Can be reset during operation.)
