4-171
4-4 Communication Function
4
Functions
002Eh
ODc (analog O disconnection
detection)
R
1: ON
0: OFF
002Fh
OIDc (analog OI disconnection
detection)
R
1: ON
0: OFF
0030h
O2Dc (analog O2 disconnection
detection)
R
1: ON
0: OFF
0031h Not used
0032h FBV (PID FB status output) R
1: ON
0: OFF
0033h NDc (network error) R
1: ON
0: OFF
0034h LOG1 (logic operation output 1) R
1: ON
0: OFF
0035h LOG2 (logic operation output 2) R
1: ON
0: OFF
0036h LOG3 (logic operation output 3) R
1: ON
0: OFF
0037h LOG4 (logic operation output 4) R
1: ON
0: OFF
0038h LOG5 (logic operation output 5) R
1: ON
0: OFF
0039h LOG6 (logic operation output 6) R
1: ON
0: OFF
003Ah WAC (capacitor life warning) R
1: ON
0: OFF
003Bh WAF (cooling fan life warning) R
1: ON
0: OFF
003Ch FR (starting contact signal) R
1: ON
0: OFF
003Dh OHF (fin overheat warning) R
1: ON
0: OFF
003Eh LOC (low current signal) R
1: ON
0: OFF
003Fh Not used
0040h Not used
0041h Not used
0042h Not used
0043h Not used
0044h Not used
0045h IRDY (operation ready) R
1: ON
0: OFF
0046h FWR (forward run signal) R
1: ON
0: OFF
Coil No. Item R/W Description
*1. When either the control circuit terminal block or the coil is turned on, these settings are ON.
The control circuit terminal block has the priority for the multi-function input terminals.
If the master cannot reset the coil ON status because of communication disconnection, turn the control
circuit terminal block from ON to OFF to turn off the coil.
*2. The communications error is retained until a fault reset is input. (Can be reset during operation.)
