Omron RX - Page 282

4-177
4-4 Communication Function
4
Functions
1005h
PID feedback value monitor
d004
(HIGH)
R 0 to 9990 0.1 [%]
1006h
d004
(LOW)
1007h Multi-function input monitor d005 R
2^0: Terminal 1 to 2^7: Terminal 8
2^8: Terminal FW

1008h
Multi-function output
monitor
d006 R
2^0: Terminal 11 to 2^4: Terminal 15
2^6: Relay terminal

1009h
Output frequency monitor
(after conversion)
d007
(HIGH)
R 0 to 39960 0.01
100Ah
d007
(LOW)
100Bh
Real frequency monitor
d008
(HIGH)
R
-40000 to +40000 0.01 [Hz]
100Ch
d008
(LOW)
R
100Dh Torque reference monitor d009 R -200 to +200 1 [%]
100Eh Torque bias monitor d010 R -200 to +200 1 [%]
100Fh Not used  
1010h Output torque monitor d012 R -200 to +200 1 [%]
1011h Output voltage monitor d013 R 0 to 6000 0.1 [V]
1012h Input power monitor d014 R 0 to 9999 0.1 [kW]
1013h
Integrated power monitor
d015
(HIGH)
R 0 to 9999999 0.1 [h]
1014h
d015
(LOW)
1015h
Total RUN time
d016
(HIGH)
R 0 to 999900 0.1 [kW]
1016h
d016
(LOW)
1017h
Power ON time monitor
d017
(HIGH)
R 0 to 999900 1 [h]
1018h
d017
(LOW)
1019h Fin temperature monitor d018 R -200 to 2000 0.1 [
C]
101Ah Motor temperature monitor d019 R -200 to 2000 0.1 [
C]
101Bh
Not used  
101Ch
101Dh Life assessment monitor d022 R
2^0: Capacitor on the main circuit board
2^1: Cooling fan rotation speed
reduced

101Eh
to
1025h
Not used  
1026h DC voltage monitor d102 R 0 to 9999 0.1 [V]
1027h
Regenerative braking load
rate monitor
d103 R 0 to 1000 0.1 [%]
1028h Electronic thermal monitor d104 R 0 to 1000 0.1 [%]
1029h
to
1033h
Not used  
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Rresolution
