4-4 Communication Function
4
Functions
1203h Base frequency A003 R/W 30 to Max. frequency 1 [Hz]
1204h Maximum frequency A004 R/W 30 to 400 1 [Hz]
1205h O/OI selection A005 R/W
0: Switches between O/OI
1: Switches between O/O2
2: Switches between O/VR
3: Switches between OI/VR
4: Switches between O2/VR

1206h O2 selection A006 R/W
0: O2 only
1: O/OI auxiliary speed (not reversible)
2: O/OI auxiliary speed (reversible)
3: O2 disabled

1207h
to
120Ah
Not used  
120Bh
O start frequency
A011
(HIGH)
R/W 0 to 40000 0.01 [Hz]
120Ch
A011
(LOW)
120Dh
O end frequency
A012
(HIGH)
R/W 0 to 40000 0.01 [Hz]
120Eh
A012
(LOW)
120Fh O start ratio A013 R/W O to Oend ratio 1 [%]
1210h O end ratio A014 R/W O start ratio to 100 1 [%]
1211h O start selection A015 R/W
0: External start frequency
1: 0 Hz

1212h O, O2, OI sampling A016 R/W
1 to 30
31: 500-ms filter with a hysteresis of
±0.1 Hz
1
1213h Not used  
1214h Not used  
1215h Multi-step speed selection A019 R/W
0: Binary
1: Bit

1216h
Multi-step speed
reference 0
A020
(HIGH)
R/W
0/Starting frequency to Max. frequency 0.01 [Hz]
1217h
A020
(LOW)
R/W
1218h
Multi-step speed
reference 1
A021
(HIGH)
R/W
0/Starting frequency to Max. frequency 0.01 [Hz]
1219h
A021
(LOW)
R/W
121Ah
Multi-step speed
reference 2
A022
(HIGH)
R/W
0/Starting frequency to Max. frequency 0.01 [Hz]
121Bh
A022
(LOW)
R/W
121Ch
Multi-step speed
reference 3
A023
(HIGH)
R/W
0/Starting frequency to Max. frequency 0.01 [Hz]
121Dh
A023
(LOW)
R/W
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
