4-181
4-4 Communication Function
4
Functions
1236h Not used  
1237h Not used  
1238h Jogging frequency A038 R/W Starting frequency to 999 0.01 [Hz]
1239h Jogging stop selection A039 R/W
0: Free-run stop/Disabled in operation
1: Deceleration stop/Disabled in
operation
2: DC injection braking stop/Disabled in
operation
3: Free-run stop/Enabled in operation
4: Deceleration stop/Enabled in
operation
5: DC injection braking stop/Enabled in
operation

123Ah Not used  
123Bh Torque boost selection A041 R/W
0: Manual torque boost
1: Automatic torque boost

123Ch
Manual torque boost
voltage
A042 R/W 0 to 200 0.1 [%]
123Dh
Manual torque boost
frequency
A043 R/W 0 to 500 0.1 [%]
123Eh
V/f characteristics
selection
A044 R/W
0: VC
1: Special VP
2: Free V/f
3: Sensorless vector
4: 0-Hz sensorless vector
5: Sensor vector

123Fh Output voltage gain A045 R/W 20 to 100 1 [%]
1240h
Automatic torque boost
voltage compensation
gain
A046 R/W 0 to 255 1 [%]
1241h
Automatic torque boost
slip compensation gain
A047 R/W 0 to 255 1 [%]
1242h
to
1244h
Not used  
1245h
DC injection braking
selection
A051 R/W
0: Disabled
1: Enabled
2: Operates only at the set frequency.

1246h
DC injection braking
frequency
A052 R/W 0 to 40000 0.01 [Hz]
1247h
DC injection braking delay
time
A053 R/W 0 to 50 0.1 [s]
1248h
DC injection braking
power
A054 R/W
0 to 100 (0.4 to 55 kW)
0 to 80 (75 to 132 kW)
1 [%]
1249h DC injection braking time A055 R/W 0 to 600 0.1 [s]
124Ah
DC injection braking
method selection
A056 R/W
0: Edge operation
1: Level operation

124Bh
Startup DC injection
braking power
A057 R/W
0 to 100 (0.4 to 55 kW)
0 to 80 (75 to 132 kW)
1 [%]
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
