4-4 Communication Function
4
Functions
124Ch
Startup DC injection
braking time
A058 R/W 0 to 600 0.1 [s]
124Dh
DC injection braking
carrier frequency
A059 R/W
5 to 150 (0.4 to 55 kW)
5 to 100 (75 to 132 kW)
0.1 [kHz]
124Eh Not used  
124Fh
Frequency upper limit
A061
(HIGH)
R/W
0/Frequency lower limit to
Max. frequency
0.01 [Hz]
1250h
A061
(LOW)
R/W
1251h
Frequency lower limit
A062
(HIGH)
R/W
0/Starting frequency to
Frequency upper limit
0.01 [Hz]
1252h
A062
(LOW)
R/W
1253h
Jump frequency 1
A063
(HIGH)
R/W
0 to 40000 0.01 [Hz]
1254h
A063
(LOW)
R/W
1255h Jump frequency width 1 A064 R/W 0 to 1000 0.01 [Hz]
1256h
Jump frequency 2
A065
(HIGH)
R/W
0 to 40000 0.01 [Hz]
1257h
A065
(LOW)
R/W
1258h Jump frequency width 2 A066 R/W 0 to 1000 0.01 [Hz]
1259h
Jump frequency 3
A067
(HIGH)
R/W
0 to 40000 0.01 [Hz]
125Ah
A067
(LOW)
R/W
125Bh Jump frequency width 3 A068 R/W 0 to 1000 0.01 [Hz]
125Ch
Acceleration stop
frequency
A069
(HIGH)
R/W
0 to 40000 0.01 [Hz]
125Dh
A069
(LOW)
R/W
125Eh Acceleration stop time A070 R/W 0 to 600 0.1 [s]
125Fh PID selection A071 R/W
0: Disabled
1: Enabled
2: Reverse output enabled

1260h PID P gain A072 R/W 2 to 50 0.1
1261h PID I gain A073 R/W 0 to 36000 0.1 [s]
1262h PID D gain A074 R/W 0 to 10000 0.01 [s]
1263h PID scale A075 R/W 1 to 9999 0.01
1264h PID feedback selection A076 R/W
0: Input OI
1: Input O
2: RS485 communication
3: Pulse train frequency
10: Operation function output

1265h Reverse PID function A077 R/W
0: Disabled
1: Enabled

Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
