4-188
4-4 Communication Function
4
Functions
1328h Initial screen selection b038 R/W
0: Screen on which the Enter key was last
pressed
1: d001
2: d002
3: d003
4: d007
5: F001

1329h
User parameter automatic
setting function selection
b039 R/W
0: Disabled
1: Enabled

132Ah Torque limit selection b040 R/W
0: Four-quadrant separate setting
1: Terminal switching
2: Analog Input
3: Option 1
4: Option 2

132Bh
Torque limit 1
(Four-quadrant mode
forward power running)
b041 R/W
0 to 200 (0.4 to 55 kW)/
0 to 180 (75 to 132 kW)/255 (no)
1 [%]
132Ch
Torque limit 2
(Four-quadrant mode
reversed regeneration)
b042 R/W
0 to 200 (0.4 to 55 kW)/
0 to 180 (75 to 132 kW)/255 (no)
1 [%]
132Dh
Torque limit 3
(Four-quadrant mode
reversed power running)
b043 R/W
0 to 200 (0.4 to 55 kW)/
0 to 180 (75 to 132 kW)/255 (no)
1 [%]
132Eh
Torque limit 4
(Four-quadrant mode
forward regeneration)
b044 R/W
0 to 200 (0.4 to 55 kW)/
0 to 180 (75 to 132 kW)/255 (no)
1 [%]
132Fh
Torque LADSTOP
selection
b045 R/W
0: Disabled
1: Enabled

1330h
Reverse rotation
prevention selection
b046 R/W
0: Disabled
1: Enabled

1331h
to
1333h
Not used  
1334h
Selection of non-stop
function at momentary
power interruption
b050 R/W
0: Disabled
1: Deceleration stop
2: Momentary power interruption non-
stop (without recovery)
3: Momentary power interruption non-
stop (with recovery)

1335h
Starting voltage of
non-stop function at
momentary power
interruption
b051 R/W 0 to 10000 0.1 [V]
1336h
Starting deceleration level
of non-stop function at
momentary power
interruption
b052 R/W 0 to 10000 0.1 [V]
1337h
Deceleration time of
non-stop function at
momentary power
interruption
b053
(HIGH)
R/W
0 to 360000 0.01 [s]
1338h
b053
(LOW)
R/W
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
