Omron RX - Page 295

4-190
4-4 Communication Function
4
Functions
1348h Not used  
1349h
Analog operation level at
O disconnection
b070 R/W 0 to 100/255 (no) 1 [%]
134Ah
Analog operation level at
OI disconnection
b071 R/W 0 to 100/255 (no) 1 [%]
134Bh
Analog operation level at
O2 disconnection
b072 R/W -100 to 100/127 (no) 1 [%]
134Ch
to
1350
Not used  
1351h Integrated power clear b078 R/W Clear by writing 1 
1352h
Integrated power display
gain
b079 R/W 1 to 1000 1
1353h Not used  
1354h Not used  
1355h Starting frequency b082 R/W 10 to 999 0.01 [Hz]
1356h Carrier frequency b083 R/W
5 to 150 (0.4 to 55 kW)
5 to 100 (75 to 132 kW)
0.1 [kHz]
1357h Initialization selection b084 R/W
0: Clears the trip monitor
1: Initializes data
2:
Clears the trip monitor and initializes
data

1358h
Initialization parameter
selection
b085 R/W Do not change. 
1359h
Frequency conversion
coefficient
b086 R/W 1 to 999 0.1
135Ah STOP key selection b087 R/W
0: Enabled
1: Disabled
2: Disabled only during stop

135Bh Free-run stop selection b088 R/W
0: 0-Hz start
1: Frequency matching start
2: Active Frequency Matching restart

135Ch
Automatic carrier
frequency reduction
b089 R/W
0: Disabled
1: Enabled

135Dh
Usage rate of regenerative
braking function
b090 R/W 0 to 1000 0.1 [%]
135Eh Stop selection b091 R/W
0: Deceleration  Stop
1: Free-run stop

135Fh Cooling fan control b092 R/W
0: Always ON
1: ON during RUN

1360h Not used  
1361h Not used  
1362h
Regenerative braking
function operation
selection
b095 R/W
0: Disabled
1: Enabled (disabled during stop)
2: Enabled (also during stop)

1363h
Regenerative braking
function ON level
b096 R/W
330 to 380
660 to 760
1 [V]
1364h Not used  
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
