4-191
4-4 Communication Function
4
Functions
1365h Thermistor selection b098 R/W
0: Disabled
1: PTC enabled
2: NTC enabled

1366h Thermistor error level b099 R/W 0 to 9999 1 []
1367h Free V/f frequency 1 b100 R/W 0 to Free V/f frequency 2 1 [Hz]
1368h Free V/f voltage 1 b101 R/W 0 to 8000 0.1 [V]
1369h Free V/f frequency 2 b102 R/W 0 to Free V/f frequency 2 1 [Hz]
136Ah Free V/f voltage 2 b103 R/W 0 to 8000 0.1 [V]
136Bh Free V/f frequency 3 b104 R/W 0 to Free V/f frequency 2 1 [Hz]
136Ch Free V/f voltage 3 b105 R/W 0 to 8000 0.1 [V]
136Dh Free V/f frequency 4 b106 R/W 0 to Free V/f frequency 2 1 [Hz]
136Eh Free V/f voltage 4 b107 R/W 0 to 8000 0.1 [V]
136Fh Free V/f frequency 5 b108 R/W 0 to Free V/f frequency 2 1 [Hz]
1370h Free V/f voltage 5 b109 R/W 0 to 8000 0.1 [V]
1371h Free V/f frequency 6 b110 R/W 0 to Free V/f frequency 2 1 [Hz]
1372h Free V/f voltage 6 b111 R/W 0 to 8000 0.1 [V]
1373h Free V/f frequency 7 b112 R/W 0 to Free V/f frequency 2 1 [Hz]
1374h Free V/f voltage 7 b113 R/W 0 to 8000 0.1 [V]
1375h
to
137Ah
Not used  
137Bh Brake control selection b120 R/W
0: Disabled
1: Enabled

137Ch Brake wait time for release b121 R/W 0 to 500 0.01 [s]
137Dh
Brake wait time for
acceleration
b122 R/W 0 to 500 0.01 [s]
137Eh
Brake wait time for
stopping
b123 R/W 0 to 500 0.01 [s]
137Fh
Brake wait time for
confirmation
b124 R/W 0 to 500 0.01 [s]
1380h Brake release frequency b125 R/W 0 to 40000 0.01 [Hz]
1381h Brake release current b126 R/W
0 to 2000 (0.4 to 55 kW)
0 to 1800 (75 to 132 kW)
0.1 [%]
1382h Brake input frequency b127 R/W 0 to 40000 0.01 [Hz]
1383h Not used  
1384h Not used  
1385h
Overvoltage protection
function selection during
deceleration
b130 R/W
0: Disabled
1: DC voltage kept constant
2: Acceleration enabled

1386h
Overvoltage protection
level during deceleration
b131 R/W
200-V class: 330 to 390 (V)
400-V class: 660 to 780 (V)
1 [V]
1387h
Overvoltage protection
parameter
b132 R/W 10 to 3000 0.01 [s]
1388h
Overvoltage protection
proportional gain setting
b133 R/W 0 to 255 0.01
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
