Omron RX - Page 301

4-196
4-4 Communication Function
4
Functions
1426h
Light load signal output
mode
C038 R/W
0: Enabled during acceleration/
deceleration/constant speed
1: Enabled only during constant speed

1427h Light load detection level C039 R/W
0 to 2000 (0.4 to 55 kW)
0 to 1800 (75 to 132 kW)
0.1 [%]
1428h
Overload warning signal
output mode
C040 R/W
0: Enabled during acceleration/
deceleration/constant speed
1: Enabled only during constant speed

1429h Overload warning level C041 R/W
0.0: Does not operate.
0 to 2000 (0.4 to 55 kW)
0 to 1800 (75 to 132 kW)
0.1 [%]
142Ah
Arrival frequency during
acceleration
C042
(HIGH)
R/W
0 to 40000 0.01 [Hz]
142Bh
C042
(LOW)
R/W
142Ch
Arrival frequency during
deceleration
C043
(HIGH)
R/W
0 to 40000 0.01 [Hz]
142Dh
C043
(LOW)
R/W
142Eh
PID deviation excessive
level
C044 R/W 0 to 1000 0.1 [%]
142Fh
Arrival frequency during
acceleration 2
C045
(HIGH)
R/W
0 to 40000 0.01 [Hz]
1430h
C045
(LOW)
R/W
1431h
Arrival frequency during
deceleration 2
C046
(HIGH)
R/W
0 to 40000 0.01 [Hz]
1432h
C046
(LOW)
R/W
1433h
to
1437h
Not used  
1438h PID FB upper limit C052 R/W 0 to 1000 0.1 [%]
1439h PID FB lower limit C053 R/W 0 to 1000 0.1 [%]
143Ah Not used  
143Bh
Overtorque level
(Forward power running)
C055 R/W
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
1 [%]
143Ch
Overtorque level
(Reverse regeneration)
C056 R/W
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
1 [%]
143Dh
Overtorque level
(Reverse power running)
C057 R/W
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
1 [%]
143Eh
Overtorque level
(Forward regeneration)
C058 R/W
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
1 [%]
143Fh Not used  
1440h Not used  
1441h Thermal warning level C061 R/W 0 to 100 1 [%]
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
