4-197
4-4 Communication Function
4
Functions
1442h Alarm code selection C062 R/W
0: Disabled
1: 3 bits
2: 4 bits

1443h 0-Hz detection level C063 R/W 0 to 10000
0.01
[Hz]
1444h Fin overheat warning level C064 R/W 0 to 200 1 [
C]
1445h
to
144Ah
Not used  
144Bh
Communication speed
selection
(Baud rate selection)
C071 R/W
2: Loop-back test
3: 2400 bps
4: 4800 bps
5: 9600 bps
6: 19200 bps

144Ch
Communication station
No. selection
C072 R/W 1 to 32 
144Dh
Communication bit length
selection
C073 R/W
7: 7 bits
8: 8 bits

144Eh
Communication parity
selection
C074 R/W
0: No parity
1: Even
2: Odd

144Fh
Communication stop bit
selection
C075 R/W
1: 1 bit
2: 2 bits

1450h
Communication error
selection
C076 R/W
0: Trip
1: Trip after deceleration stop
2: Ignore
3: Free-run stop
4: Deceleration stop

1451h
Communication error
timeout
C077 R/W 0 to 9999 0.01 [s]
1452h Communication wait time C078 R/W 0 to 1000 1 [ms]
1453h
Communication method
selection
C079 R/W
0: ASCII
1: ModBus-RTU

1454h Not used  
1455h O adjustment C081 R/W 0 to 65530 1
1456h OI adjustment C082 R/W 0 to 65530 1
1457h O2 adjustment C083 R/W 0 to 65530 1
1458h Not used  
1459h Thermistor adjustment C085 R/W 0 to 10000 0.1
145Ah
to
145Eh
Not used  
145Fh Not used  
1460h
to
1468h
Not used  
1469h UP/DWN selection C101 R/W
0: Does not store the frequency data
1: Stores the frequency data

Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
