4-4 Communication Function
4
Functions
146Ah Reset selection C102 R/W
0: Trip reset at power-on
1: Trip reset at power-off
2: Enabled only during trip (Reset at
power-on)
3: Trip reset only

146Bh
Reset frequency matching
selection
C103 R/W
0: 0-Hz start
1: Frequency matching start
2: Active Frequency Matching restart

146Ch Not used  
146Dh FM gain setting C105 R/W 50 to 200 1 [%]
146Eh AM gain setting C106 R/W 50 to 200 1 [%]
146Fh AMI gain setting C107 R/W 50 to 200 1 [%]
1470h Not used  
1471h AM bias setting C109 R/W 0 to 100 1 [%]
1472h AMI bias setting C110 R/W 0 to 100 1 [%]
1473h Overload warning level 2 C111 R/W
0 to 2000 (0.4 to 55 kW)
0 to 1800 (75 to 132 kW)
0.1 [%]
1474h
to
147Ch
Not used  
147Dh O zero adjustment C121 R/W 0 to 65530 1
147Eh OI zero adjustment C122 R/W 0 to 65530 1
147Fh O2 zero adjustment C123 R/W 0 to 65530 1
1480h
to
1485h
Not used  
1486h Output 11 ON delay C130 R/W
0 to 1000
0.1 [s]
1487h Output 11 OFF delay C131 R/W 0.1 [s]
1488h Output 12 ON delay C132 R/W 0.1 [s]
1489h Output 12 OFF delay C133 R/W 0.1 [s]
148Ah Output 13 ON delay C134 R/W 0.1 [s]
148Bh Output 13 OFF delay C135 R/W 0.1 [s]
148Ch Output 14 ON delay C136 R/W 0.1 [s]
148Dh Output 14 OFF delay C137 R/W 0.1 [s]
148Eh Output 15 ON delay C138 R/W 0.1 [s]
148Fh Output 15 OFF delay C139 R/W 0.1 [s]
1490h Relay output ON delay C140 R/W 0.1 [s]
1491h Relay output OFF delay C141 R/W 0.1 [s]
1492h
Logic output signal 1
selection 1
C142 R/W
Same as C021 to C026
(except LOG1 to 6)

1493h
Logic output signal 1
selection 2
C143 R/W
Same as C021 to C026
(except LOG1 to 6)

1494h
Logic output signal 1
operator selection
C144 R/W
0: AND
1: OR
2: XOR

Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
