4-4 Communication Function
4
Functions
1495h
Logic output signal 2
selection 1
C145 R/W
Same as C021 to C026
(except LOG1 to 6)

1496h
Logic output signal 2
selection 2
C146 R/W
Same as C021 to C026
(except LOG1 to 6)

1497h
Logic output signal 2
operator selection
C147 R/W
0: AND
1: OR
2: XOR

1498h
Logic output signal 3
selection 1
C148 R/W
Same as C021 to C026
(except LOG1 to 6)

1499h
Logic output signal 3
selection 2
C149 R/W
Same as C021 to C026
(except LOG1 to 6)

149Ah
Logic output signal 3
operator selection
C150 R/W
0: AND
1: OR
2: XOR

149Bh
Logic output signal 4
selection 1
C151 R/W
Same as C021 to C026
(except LOG1 to 6)

149Ch
Logic output signal 4
selection 2
C152 R/W
Same as C021 to C026
(except LOG1 to 6)

149Dh
Logic output signal 4
operator selection
C153 R/W
0: AND
1: OR
2: XOR

149Eh
Logic output signal 5
selection 1
C154 R/W
Same as C021 to C026
(except LOG1 to 6)

149Fh
Logic output signal 5
selection 2
C155 R/W
Same as C021 to C026
(except LOG1 to 6)

14A0h
Logic output signal 5
operator selection
C156 R/W
0: AND
1: OR
2: XOR

14A1h
Logic output signal 6
selection 1
C157 R/W
Same as C021 to C026
(except LOG1 to 6)

14A2h
Logic output signal 6
selection 2
C158 R/W
Same as C021 to C026
(except LOG1 to 6)

14A3h
Logic output signal 6
operator selection
C159 R/W
0: AND
1: OR
2: XOR

14A4h
Input terminal response
time 1
C160 R/W 0 to 200 (× 2 ms) 1
14A5h
Input terminal response
time 2
C161 R/W 0 to 200 (× 2 ms) 1
14A6h
Input terminal response
time 3
C162 R/W 0 to 200 (× 2 ms) 1
14A7h
Input terminal response
time 4
C163 R/W 0 to 200 (× 2 ms) 1
14A8h
Input terminal response
time 5
C164 R/W 0 to 200 (× 2 ms) 1
14A9h
Input terminal response
time 6
C165 R/W 0 to 200 (× 2 ms) 1
14AAh
Input terminal response
time 7
C166 R/W 0 to 200 (× 2 ms) 1
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
