4-206
4-4 Communication Function
4
Functions
* Data on H003 (motor capacity selection) is the following code data.
<Holding Register Number List (2nd Setting)>
<Holding Register Number List (Function Mode 2nd Setting)>
Code data 00 01 02 03 04 05 06 07 08 09 10
Motor capacity (kW) 0.2 0.4 0.75 1.5 2.2 3.7
Code data 11 12 13 14 15 16 17 18 19 20 21
Motor capacity (kW) 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Code data 22 23 24 25 26
Motor capacity (kW) 90 110 132 150 160
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
2103h
2nd acceleration time 1
F202
(HIGH)
R/W
1 to 360000 0.01 [s]
2104h
F202
(LOW)
R/W
2105h
2nd deceleration time 1
F203
(HIGH)
R/W
1 to 360000 0.01 [s]
2106h
F203
(LOW)
R/W
2107h
to
2202h
Not used
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
2203h 2nd base frequency A203 R/W 30 to 2nd max. frequency 1 [Hz]
2204h 2nd max. frequency A204 R/W 30 to 400 1 [Hz]
2205h
to
2215h
Not used
2216h
2nd multi-step speed
reference 0
A220
(HIGH)
R/W
0, Starting frequency to 2nd max.
frequency
0.01 [Hz]
2217h
A220
(LOW)
R/W
2218h
to
223Ah
Not used
223Bh 2nd torque boost selection A241 R/W
0: Manual torque boost
1: Automatic torque boost
223Ch
2nd manual torque boost
voltage
A242 R/W 0 to 200 0.1 [%]
223Dh
2nd manual torque boost
frequency
A243 R/W 0 to 500 0.1 [%]
223Eh
2nd V/f characteristics
selection
A244 R/W
0: VC
1: Special VP
2: Free V/f
3: Sensorless vector
4: 0-Hz sensorless vector
223Fh Not used
