Omron RX - Page 312

4-207
4-4 Communication Function
4
Functions
2240h
2nd automatic torque
boost voltage
compensation gain
A246 R/W 0 to 255 1
2241h
*2nd automatic torque
boost slip compensation
gain
A247 R/W 0 to 255 1
2242h
to
224Eh
Not used  
224Fh
2nd frequency upper limit
A261
(HIGH)
R/W
0, 2nd frequency lower limit to
2nd max. frequency
0.01 [Hz]
2250h
A261
(LOW)
R/W
2251h
2nd frequency lower limit
A262
(HIGH)
R/W
0, Starting frequency to
2nd frequency upper limit
0.01 [Hz]
2252h
A262
(LOW)
R/W
2253h
to
226Eh
Not used  
226Fh
2nd acceleration time 2
A292
(HIGH)
R/W
1 to 360000 0.01 [s]
2270h
A292
(LOW)
R/W
2271h
2nd deceleration time 2
A293
(HIGH)
R/W
1 to 360000 0.01 [s]
2272h
A293
(LOW)
R/W
2273h
2nd 2-step acceleration/
deceleration selection
A294 R/W
0: Switched via terminal 2CH
1: Switched by setting
2: Switched at forward/reverse
inversion only

2274h
2nd 2-step acceleration
frequency
A295
(HIGH)
R/W
0 to 40000 0.01 [Hz]
2275h
A295
(LOW)
R/W
2276h
2nd 2-step deceleration
frequency
A296
(HIGH)
R/W
0 to 40000 0.01 [Hz]
2277h
A296
(LOW)
R/W
2278h
to
230Bh
Not used  
230Ch
2nd electronic thermal
level
b212 R/W 200 to 1000 0.1 [%]
230Dh
2nd electronic thermal
characteristics selection
b213 R/W
0: Reduction characteristics
1: Constant torque characteristics
2: Free setting

Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
