4-210
4-4 Communication Function
4
Functions
<Holding Register Number List (Function Mode 3rd Setting)>
3105h
3rd deceleration time 1
F303
(HIGH)
R/W
1 to 360000 0.01 [s]
3106h
F303
(LOW)
R/W
3107h
to
3202h
Not used  
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
3203h 3rd base frequency A303 R/W 30 to 3rd max. frequency 1 [Hz]
3204h 3rd maximum frequency A304 R/W 30 to 400 1 [Hz]
3205h to
3215h
Not used  
3216h
3rd multi-step speed
reference 0
A320
(HIGH)
R/W
0, Starting frequency to 3rd max.
frequency
0.01 [Hz]
3217h
A320
(LOW)
R/W
3218h to
323Bh
Not used  
323Ch
3rd manual torque boost
voltage
A342 R/W 0 to 200 0.1 [%]
323Dh
3rd manual torque boost
frequency
A343 R/W 0 to 500 0.1 [%]
323Eh
3rd V/f characteristics
selection
A344 R/W
0: VC
1: VP

323Fh to
326Ch
Not used  
326Dh
3rd acceleration time 2
A392
(HIGH)
R/W
1 to 360000 0.01 [s]
326Eh
A392
(LOW)
R/W
326Fh
3rd deceleration time 2
A393
(HIGH)
R/W
1 to 360000 0.01 [s]
3270h
A393
(LOW)
R/W
3271h to
330B
Not used  
330Ch
3rd electronic thermal
level
b312 R/W 200 to 1000 0.1 [%]
330Dh
3rd electronic thermal
characteristics selection
b313 R/W
0: Reduced torque characteristics
1: Constant torque characteristics
2: Free setting

330Eh to
3506h
Not used  
3507h 3rd stabilization parameter H306 R/W 0 to 255 1
From
3508h
Not used  
