7-25
7-3 Options
7
Specifications
Specifications
Voltage Reference
Dimensions Weight
Kg
A B1
B2 C1 C2 D E F
200V
AX-RAI02800100-DE
120
-
80
-
120 80 62 5.5 2.35
AX-RAI00880200-DE
AX-RAI00350335-DE
180
85
190
140
55
6
5.5
AX-RAI00180670-DE
AX-RAI00091000-DE 205 6.5
AX-RAI00071550-DE 105 205 85 11.7
AX-RAI00042300-DE 240 130 - 210 - 200 75 16.0
400V
AX-RAI07700050-DE
120
-
70
120 80
52
5.5
1.78
AX-RAI03500100-DE
80 62
2.35
AX-RAI01300170-DE 2.5
AX-RAI00740335-DE
180
85
190
140
55
6
5.5
AX-RAI00360500-DE
205
6.5
AX-RAI00290780-DE 105 85 11.7
AX-RAI00191150-DE 240 110 275 200 75 16.0
Voltage
Max. applicable
motor output kW
Reference
Current value
A
Inductance
mH
3 phase 200V
0.4 to 1.5 AX-RAI02800100-DE 10.0 2.8
2.2 to 3.7 AX-RAI00880200-DE 20.0 0.88
5.5 to 7.5 AX-RAI00350335-DE 33.5 0.35
11.0 to 15.0 AX-RAI00180670-DE 67.0 0.18
18.5 to 22.0 AX-RAI00091000-DE 100.0 0.09
30.0 to 37.0 AX-RAI00071550-DE 155.0 0.07
45.0 to 55.0 AX-RAI00042300-DE 230.0 0.04
3 phase 400V
0.4 to 1.5 AX-RAI07700050-DE
5.0 7.7
2.2 to 3.7 AX-RAI03500100-DE 10.0 3.5
5.5 to 7.5 AX-RAI01300170-DE
17.0 1.3
11.0 to 15.0 AX-RAI00740335-DE
33.5 0.74
18.5 to 22.0 AX-RAI00360500-DE
50.0 0.36
30.0 to 37.0 AX-RAI00290780-DE
78.0 0.29
45.0 to 55.0 AX-RAI00191150-DE
115.0 0.19
