3-9
3-4 Part Names and Descriptions of the Digital Operator
3
Operation
Display System and Key Sequence of Each Code
• This section explains the examples of typical operation (Basic display, Complete display) and the
extended function mode U as a special operation.
This operation can be performed when other display modes are selected.
Note: The Digital Operator display varies depending on the settings of display selection "b037", ini-
tial screen selection "b038", and user parameter automatic setting function selection "b039".
For details, refer to "Display Selection" (page 4-53), "Initial Screen Selection (Initial Screen
at Power-ON)" (page 4-56), "User Parameter Automatic Setting Function" (page 4-57).
*Not displayed by factory default.
* To return the display to or
*
from any display on the Digital Operator, refer to
the following procedures.
• Hold down the Mode key for 3 seconds or more to display and
*
alternately.
Press the Mode key to display or
*
.
* shows the status during stop. Displays the output frequency of the Inverter during
operation.
Decrement key Changes the mode.
Also, decreases the set value of each function.
Name Function
The display indicates the setting of "b038" when the power is turned on. For details, refer to
"Initial Screen Selection (Initial Screen at Power-ON)" (page 4-56).
When "b038 = 01" (factory default), for output frequency monitor "d001" is displayed.
Press the Mode key to display .
0.00
dk0k0k1
Item Function code Data Description
Display selection b037
00 Complete display
01 Individual display of functions
02 User setting
03 Data comparison display
04 Basic display (factory default)
Initial screen
selection
(Power On)
b038 *
00 Screen when the Enter key was pressed last
01 d001 (Output frequency monitor) (factory default)
02 d002 (Output current monitor)
03 d003 (Rotation direction monitor)
04 d007 (Frequency conversion monitor)
05 F001 (Output frequency setting/monitor)
User parameter
automatic setting
function selection
b039
*
00 Disabled (factory default)
01 Enabled
dk0k0k1
0.00
dk0k0k1
0.00
dk0k0k1
0.00
0.00
