3-7 Parameter List
3
Operation
Multi-function output terminal
C031
Multi-function output
terminal 11 contact
selection
00: NO contact at AL2; NC contact at AL1
01: NC contact at AL2; NO contact at AL1
00
No  4-94
C032
Multi-function output
terminal 12 contact
selection
C033
Multi-function output
terminal 13 contact
selection
C034
Multi-function output
terminal 14 contact
selection
C035
Multi-function output
terminal 15 contact
selection
C036
Relay output (AL2,
AL1) contact
selection
01
Level and output terminal status
C038
Light load signal
output mode
00: Enabled during acceleration/deceleration/
constant speed
01: Enabled only during constant speed
01 No 
4-104
C039
Light load detection
level
0.0 to 2.00 × Rated current (0.4 to 55 kW)
0.0 to 1.80 × Rated current (75 to 132 kW)
Rated
current
No A
C040
Overload warning
signal output mode
00: Enabled during acceleration/deceleration/
constant speed
01: Enabled only during constant speed
01 No 
4-49
C041
Overload warning
level
0.0: Does not operate.
0.1 × Rated current to 2.00 × Rated current
(0.4 to 55 kW)
0.1 × Rated current to 1.80 × Rated current
(75 to 132 kW)
Rated
current
No A
C042
Arrival frequency
during acceleration
0.00 to 99.99
100.0 to 400.0
0.00 No Hz
4-96
C043
Arrival frequency
during deceleration
0.00 to 99.99
100.0 to 400.0
0.00 No Hz
C044
PID deviation
excessive level
0.0 to 100.0 3.0 No % 4-31
C045
Arrival frequency
during acceleration 2
0.00 to 99.99
100.0 to 400.0
0.00 No Hz
4-96
C046
Arrival frequency
during deceleration 2
0.00 to 99.99
100.0 to 400.0
0.00 No Hz
C052
PID FB upper limit 0.0 to 100.0 100.0 No %
4-31
C053
PID FB lower limit 0.0 to 100.0 0.0 No %
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
