3-44
3-7 Parameter List
3
Operation
Adjustment
C081 O adjustment
0. to 9999.
1000 to 6553 (10000 to 65530)
Factory
default
Yes 
C082 OI adjustment
0. to 9999.
1000 to 6553 (10000 to 65530)
Factory
default
Yes 
C083 O2 adjustment
0. to 9999.
1000 to 6553 (10000 to 65530)
Factory
default
Yes 
C085
Thermistor
adjustment
0.0 to 999.9
1000.
Factory
default
Yes  4-73
C091 Not used
Use "00".
* Do not change.
00 No 
Others
C101 UP/DWN selection
00: Do not store the frequency data
01: Store the frequency data
00 No  4-88
C102 Reset selection
00: Trip reset at power-on
01: Trip reset when the power is OFF
02: Enabled only during trip (Reset when the
power is ON)
03: Trip reset only
00 Yes 
4-85
4-132
C103
Reset frequency
matching selection
00: 0 Hz start
01: Frequency matching start
02: Active Frequency Matching restart
00 No  4-85
Meter adjustment
C105 FM gain setting 50. to 200. 100. Yes % 4-108
C106 AM gain setting 50. to 200. 100. Yes %
4-109
C107 AMI gain setting 50. to 200. 100. Yes %
C109 AM bias setting 0. to 100. 0. Yes %
C110 AMI bias setting 0. to 100. 20. Yes %
Terminal
C111
Overload warning
level 2
0.0 to 2.00 × Rated current (0.4 to 55 kW)
0.0 to 1.80 × Rated current (75 to 132 kW)
Rated
current
No A 4-49
Adjustment
C121 O zero adjustment
0. to 9999.
1000 to 6553 (10000 to 65530)
Factory
default
Yes 
C122 OI zero adjustment
0. to 9999.
1000 to 6553 (10000 to 65530)
Factory
default
Yes 
C123 O2 zero adjustment
0. to 9999.
1000 to 6553 (10000 to 65530)
Factory
default
Yes 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
