3-46
3-7 Parameter List
3
Operation
Output terminal operation function
C152
Logic output signal 4
selection 2
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
No 4-100
C153
Logic output signal 4
operator selection
00: AND
01: OR
02: XOR
00
C154
Logic output signal 5
selection 1
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C155
Logic output signal 5
selection 2
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C156
Logic output signal 5
operator selection
00: AND
01: OR
02: XOR
00
C157
Logic output signal 6
selection 1
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C158
Logic output signal 6
selection 2
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C159
Logic output signal 6
operator selection
00: AND
01: OR
02: XOR
00
Input terminal response
C160
Input terminal
response time 1
0. to 200. (× 2 ms) 1
No ms 4-106
C161
Input terminal
response time 2
0. to 200. (× 2 ms) 1
C162
Input terminal
response time 3
0. to 200. (× 2 ms) 1
C163
Input terminal
response time 4
0. to 200. (× 2 ms) 1
C164
Input terminal
response time 5
0. to 200. (× 2 ms) 1
C165
Input terminal
response time 6
0. to 200. (× 2 ms) 1
C166
Input terminal
response time 7
0. to 200. (× 2 ms) 1
C167
Input terminal
response time 8
0. to 200. (× 2 ms) 1
C168
FW terminal response
time
0. to 200. (× 2 ms) 1
Others
C169
Multi-step speed/
position
determination time
0. to 200. (× 10 ms) 0 No ms
4-16
4-132
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
