Omron STC-HD213 Series User Manual

No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
’
s Guide
22/94
4) AEE
Selects exposing operation from below two exposing operations. (Default: AUTO)
The setting is valid when selecting “ON” at “ALC”.
a) AUTO
The brightness of image will be maintaining to keep target brightness of image (with LUMINANCE
setting) with auto exposing function.
b) FIXED
The fixed exposure time operation
The fixed exposure time is adjustable with “SHUTTER”.
5) GAIN
Sets the fixed gain.
This fixed gain setting is valid when selecting “OFF” at “ALC”, or “FIXED” at “AGC”.
Setting range: 0 (0.00 dB) to 150 (45.0 dB)
6) SHUTTER
Sets the fixed exposure time.
This fixed exposure time setting is valid when selecting “OFF” at “ALC”, or “FIXED” at “AEE”.
Setting range:
1080p60 -447 (2.12 sec.) to 0 (1/60.1 sec.) to +561 (1/33,750.0 sec.)
1080p59.94 -447 (2.12 sec.) to 0 (1/60.1 sec.) to +561 (1/33,750.0 sec.)
1080p50 -447 (2.54 sec.) to 0 (1/50.1 sec.) to +561 (1/28,125.0 sec.)
1080p30 -447 (4.23 sec.) to 0 (1/30.1 sec.) to +561 (1/16,875.0 sec.)
1080p29.97 -447 (4.23 sec.) to 0 (1/30.1 sec.) to +561 (1/16,875.0 sec.)
1080p25 -447 (5.08 sec.) to 0 (1/25.0 sec.) to +561 (1/14,062.5 sec.)
1080i60 -447 (2.12 sec.) to 0 (1/60.1 sec.) to +561 (1/33,750.0 sec.)
1080i59.94 -447 (2.12 sec.) to 0 (1/60.1 sec.) to +561 (1/33,750.0 sec.)
1080i50 -447 (2.54 sec.) to 0 (1/50.1 sec.) to +561 (1/28,125.0 sec.)
720p60 -447 (2.12 sec.) to 0 (1/60.1 sec.) to +561 (1/33,750.0 sec.)
720p59.94 -447 (2.12 sec.) to 0 (1/60.1 sec.) to +561 (1/33,750.0 sec.)
720p50 -447 (2.54 sec.) to 0 (1/50.1 sec.) to +561 (1/28,125.0 sec.)
* The setting range for “Non-memory types” (STC-HD213DVN, HD213DVN-CS, HD213SDIN and
HD213SDIN-CS) is “from 0 to +561”
7) GAMMA
Sets the Gamma.
It is necessary to set manual gamma setting via UART communication.
Setting selection: MANUAL, 0.3, 0.45, 0.50, 0.60, 0.70, 0.80, 0.90 / 1.00
Default: MANUAL.
