No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
23/94
Page 2
1) WB MODE
Selects the white balance mode from below two modes. (Default: AUTO).
a) AUTO
The auto white balance operation.
b) MANUAL
The manual white balance operation with adjustable “R GAIN” and “B GAIN”.
2) R GAIN
Sets the R gain for manual white balance.
This setting is valid when selecting “MANUAL” at “WB MODE”.
Setting range: 0 to 1,023
3) B GAIN
Sets the B gain for manual white balance.
This setting is valid when selecting “MANUAL” at “WB MODE”.
Setting range: 0 to 1,023
4) SHARPNESS
Sets the sharpness (Edge enhancement) of image.
a) H
Sets the horizontal sharpness.
Setting range: 00 (Soft) to 15 (Strong)
Default: 03
b) V
Sets the vertical sharpness.
Setting range: 00 (Soft) to 15 (Strong)
Default: 03
5) CORING
The noise level also emphasizes when using sharpness function.
The SN ratio deteriorate for other than edge parts is prevented by cutting signal level that smaller than
this setting.
The image becomes soft image if this setting sets too large.
Setting range: 00 to 63
Default: 02
PAGE 1 2 3 4 5 6
WB MODE AUTO
R GAIN
B GAIN
SHARPNESS H03 V03
CORING 02
To Next Page
