Omron STC-HD213 Series User Manual

No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
’
s Guide
24/94
Page 3
1) GRAPHICS
Selects enable or disable for line makers, shadow mask and circle marker displaying. (Default: ON).
This setting is synchronizing with “GRAPHICS” on Page 4.
a) ON
The line markers, shadow mask and circle marker can be display.
Selects enable or disable “line makers” display at “LINE”
Selects enable or disable “shadow mask” display at “SHADOW” on page 4.
Selects enable or disable “circle marker” display at “CIRCLE” on page 4.
b) OFF
The line markers, shadow mask and circle marker do not display.
2) LINE
Selects enable or disable for Line markers display (Default: ON).
This setting is valid when selecting “ON” at “GRAPHICS”.
a) ON
The line makers are displaying.
Sets the color, size (thickness) and position for individual line.
The line maker does not display if size (thickness) of line is “0” or position of line is “0000” even
selecting “ON” at “LINE”.
b) OFF
The line markers do not display.
PAGE 1 2 3 4 5 6
GRAPHICS ON
LINE ON
LINE1 H POS 0000 SIZE 0000
COLOR BLACK
V POS 0000 SIZE 0000
COLOR BLACK
LINE2 H POS 0000 SIZE 0000
COLOR BLACK
V POS 0000 SIZE 0000
COLOR BLACK
