3) LINE1 (Horizontal line 1 maker and vertical line 1 maker settings)
Sets the color, size (thickness) and position for horizontal line marker 1 and vertical line marker 1.
a) H POS
Sets the position for horizontal line marker 1.
Setting range: 0 (Top) to 1,080 (Bottom)
Default: 0
b) H SIZE
Sets the size (thickness) for horizontal line marker 1.
Setting range: 0 (0 line, horizontal line marker 1 does not display) to 1,080 (1,080 lines)
Default: 0
c) H COLOR
Sets the color for horizontal line marker 1.
It is necessary to set USER0 to USER7 colors via UART communication.
Setting selection: BLACK / WHITE / RED / GREEN / BLUE / CYAN / MAGENTA / YELLOW /
USER0 / USER1 / USER2 / USER3 / USER4 / USER5 / USER6 / USER7
Default: BLACK
d) V POS
Sets the position for vertical line marker 1.
Setting range: 0 (Left end) to 1,920 (Right end)
Default: 0
e) V SIZE
Sets the size (thickness) for vertical line marker 1.
Setting range: 0 (0 pixel, vertical line marker 1 does not display) to 1,920 (1,920 pixels)
Default: 0
F) V COLOR
Sets the color for vertical line marker 1.
It is necessary to set USER0 to USER7 colors via UART communication.
Setting selection: BLACK / WHITE / RED / GREEN / BLUE / CYAN / MAGENTA / YELLOW /
USER0 / USER1 / USER2 / USER3 / USER4 / USER5 / USER6 / USER7
Default: BLACK
