Omron STC-HD213 Series User Manual

No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
’
s Guide
26/94
4) LINE2 (Horizontal line 2 maker and vertical line 2 maker settings)
Sets the color, size (thickness) and position for horizontal line marker 2 and vertical line marker 2.
a) H POS
Sets the position for horizontal line marker 2.
Setting range: 0 (Top) to 1,080 (Bottom)
Default: 0
b) H SIZE
Sets the size (thickness) for horizontal line marker 2.
Setting range: 0 (0 line, horizontal line marker 2 does not display) to 1,080 (1,080 lines)
Default: 0
c) H COLOR
Sets the color for horizontal line 2.
It is necessary to set USER0 to USER7 colors via UART communication.
Setting selection: BLACK / WHITE / RED / GREEN / BLUE / CYAN / MAGENTA / YELLOW /
USER0 / USER1 / USER2 / USER3 / USER4 / USER5 / USER6 / USER7
Default: BLACK
d) V POS
Sets the position for vertical line marker 2.
Setting range: 0 (Left end) to 1,920 (Right end)
Default: 0
e) V SIZE
Sets the size (thickness) for vertical line marker 2
Setting range: 0 (0 pixel, vertical line marker 2 does not display) to 1,920 (1,920 pixels)
Default: 0
F) V COLOR
Sets the color for vertical line 2.
It is necessary to set USER0 to USER7 colors via UART communication.
Setting selection: BLACK / WHITE / RED / GREEN / BLUE / CYAN / MAGENTA / YELLOW /
USER0 / USER1 / USER2 / USER3 / USER4 / USER5 / USER6 / USER7
Default: BLACK
