No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
29/94
3) CIRCLE
Selects enable or disable for circle maker display (Default: ON).
This setting is valid when selecting “ON” at “GRAPHICS”.
a) ON
The circle maker is displaying.
Sets the radius, line size (thickness), center position and color for circle maker.
The circle marker does not display if size (thickness) of circle is “0” even selecting “ON” at “CIRCLE”.
b) OFF
The circle maker does not display.
3-1) RADIUS
Sets the radius for circle marker.
Setting range: 000 (Filled circle) to 960
Default: 000
3-2) SIZE
Sets the size (thickness) for circle marker.
Setting range: 0 (0, circle does not display) to 480
Default: 000
3-3) H POS
Sets the horizontal center position for circle marker.
Setting range: 000 (Left end) to 1,920 (Right end)
Default: 960
3-4) V POS
Sets the vertical center position for circle marker.
Setting range: 000 (Top) to 1,080 (Bottom)
Default: 540
3-5) COLOR
Sets the color for circle.
It is necessary to set USER0 to USER7 colors via UART communication.
Setting selection: BLACK / WHITE / RED / GREEN / BLUE / CYAN / MAGENTA / YELLOW /
USER0 / USER1 / USER2 / USER3 / USER4 / USER5 / USER6 / USER7
Default: BLACK
