No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
72/94
Address
7
6
5
4
3
2
1
0
Descriptions Default
02C X
X
X
X
X
X
X
X
Default function of primary switch WB: single push
* As for the detail of selectable function, please refer to Push
button function list
2
02D X
X
X
X
X
X
X
X
Default function of external switch A: single push
* As for the detail of selectable function, please refer to Push
button function list
1
02E X
X
X
X
X
X
X
X
Default function of external switch B: single push
* As for the detail of selectable function, please refer to Push
button function list
0
02F X
X
X
X
X
X
X
X
Default function of external switch C: single push
* As for the detail of selectable function, please refer to Push
button function list
0
030 X
X
X
X
X
X
X
X
Default function of external switch D: single push
* As for the detail of selectable function, please refer to Push
button function list
0
031 X
X
X
X
X
X
X
X
Default function of external switch E: single push
* As for the detail of selectable function, please refer to Push
button function list
0
032 X
X
X
X
X
X
X
X
Default function of external switch F: single push
* As for the detail of selectable function, please refer to Push
button function list
0
033 X
X
X
X
X
X
X
X
Default function of external switch WB: hold
* As for the detail of selectable function, please refer to Push
button function list
1
034 X
X
X
X
X
X
X
X
Default function of external switch A: hold
* As for the detail of selectable function, please refer to Push
button function list
0
035 X
X
X
X
X
X
X
X
Default function of external switch B: hold
* As for the detail of selectable function, please refer to Push
button function list
0
036 X
X
X
X
X
X
X
X
Default function of external switch C: hold
* As for the detail of selectable function, please refer to Push
button function list
0
037 X
X
X
X
X
X
X
X
Default function of external switch D: hold
* As for the detail of selectable function, please refer to Push
button function list
0
038 X
X
X
X
X
X
X
X
Default function of external switch E: hold
* As for the detail of selectable function, please refer to Push
button function list
0
039 X
X
X
X
X
X
X
X
Default function of external switch F: hold
* As for the detail of selectable function, please refer to Push
button function list
0
03A X
X
X
X
X
X
X
X
Horizontal line minimum position [little-endian] (to Push Button) 0
03B 0
0
0
0
0
X
X
X
03C X
X
X
X
X
X
X
X
Horizontal line maximum position [little-endian] (to Push Button) 1,920
03D 0
0
0
0
0
X
X
X
03E X
X
X
X
X
X
X
X
Horizontal line minimum size (thickness) [little-endian]
(to Push Button)
1,920
03F 0
0
0
0
0
X
X
X
To Next Page
