No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
73/94
Address
7
6
5
4
3
2
1
0
Descriptions Default
040 X
X
X
X
X
X
X
X
Vertical line minimum position [little-endian] (to Push Button) 0
041 0
0
0
0
0
X
X
X
042 X
X
X
X
X
X
X
X
Vertical line maximum position [little-endian] (to Push Button) 1,080
043 0
0
0
0
0
X
X
X
044 X
X
X
X
X
X
X
X
Vertical line minimum size (thickness) [little-endian]
(to Push Button)
1,080
045 0
0
0
0
0
X
X
X
046 X
X
X
X
X
X
X
X
Shadow Horizontal minimum position [little-endian]
(for Push Button)
0
047 0
0
0
0
0
X
X
X
048 X
X
X
X
X
X
X
X
Shadow Horizontal maximum position [little-endian]
(for Push Button)
1,920
049 0
0
0
0
0
X
X
X
04A X
X
X
X
X
X
X
X
Shadow Vertical minimum position [little-endian]
(for Push Button)
0
04B 0
0
0
0
0
X
X
X
04C X
X
X
X
X
X
X
X
Shadow Vertical maximum position [little-endian]
(for Push Button)
1,080
04D 0
0
0
0
0
X
X
X
04E -
04F
X
X
X
X
X
X
X
X
Reserved -
050 X
X
X
OSD menu color
0: Black 1: Blue
2: Green 3: Cyan
4: Red 5: Magenta
6: Yellow 7: White
7
X
OSD character size
0: Large 1: Small
0
X
X
X
X
Reserved -
051 X
X
X
X
X
X
X
X
OSD horizontal displaying position
0: Left to 256: Right
0
052 X
X
X
X
X
X
X
X
OSD vertical displaying position
0: Top to 256: Bottom
0
053 X
X
X
X
X
X
X
X
OSD RGB level 186
054 X
X
X
X
X
X
X
X
OSD edge level 16
055 X
Still Image
0: Off (Live video) 1: On (Still image)
* This setting is valid only STC-HD213DV, HD213DV-CS,
HD213SDI and HD213SDI-CS.
0
X
X
Test Pattern selection
0: Off (Camera image) 1: Gray Scale
2: Color Bar
3: Color Bar + Gray Scale
0
X
X
X
X
X
Reserved -
056 X
X
X
X
X
X
X
Digital Zoom
M = 128 / (128 - x)
M: Magnification, x: Setting
* This setting is valid only STC-HD213DV, HD213DV-CS,
HD213SDI and HD213SDI-CS.
0
X
Reserved -
057 X
X
X
X
X
X
X
X
Reserved -
To Next Page
