No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
88/94
Address
7
6
5
4
3
2
1
0
Descriptions Default
100 X
Line Marker
0: Disable 1: Enabler
1
X
Shadow Mask
0: Disable 1: Enable
1
X
Circle Mask
0: Disable 1: Enable
1
X
X
X
X
Reserved -
X
Marker
0: Disable 1: Enable
1
101 X
X
X
X
X
X
X
X
Shadow mask shading level
0: Invisible to 255: Black
0
102 X
X
X
X
X
X
X
X
Horizontal shadow mask top position [little-endian]
0: Top to 1,080: Bottom
0
103 0
0
0
0
X
X
X
X
104 X
X
X
X
X
X
X
X
Horizontal shadow mask bottom position [little-endian]
0: Top to 1,080: Bottom
1,080
105 0
0
0
0
X
X
X
X
106 X
X
X
X
X
X
X
X
Vertical shadow mask left position [little-endian]
0: Left to 1,920: Right
0
107 0
0
0
0
X
X
X
X
108 X
X
X
X
X
X
X
X
Vertical shadow mask right position [little-endian]
0: Left to 1,920: Right
1,920
109 0
0
0
0
X
X
X
X
10A X
X
X
X
Vertical line 1 marker color
*as for the configurable color, please refer to color code chart
0
X
X
X
X
Horizontal line 1 marker color
*as for the configurable color, please refer to color code chart
0
10B X
X
X
X
X
X
X
X
Reserved -
10C X
X
X
X
X
X
X
X
Horizontal line 1 marker position [little-endian]
0: Top to 1,080: Bottom
0
10D 0
0
0
0
0
0
0
X
10E X
X
X
X
X
X
X
X
Horizontal line 1 marker thickness (size) [little-endian]
0: Invisible to 1,080: Maximum
0
10F 0
0
0
0
0
0
0
X
110 X
X
X
X
X
X
X
X
Vertical line 1 marker position [little-endian]
0: Left to 1,920: Right
0
111 0
0
0
0
0
0
0
X
112 X
X
X
X
X
X
X
X
Vertical line 1 marker thickness (size) [little-endian]
0: Invisible to 1,920: Maximum
0
113 0
0
0
0
0
0
0
X
114 X
X
X
X
Horizontal line 2 marker color
*as for the configurable color, please refer to color code chart
0
X
X
X
X
Vertical line 2 marker color
*as for the configurable color, please refer to color code chart
9
115 X
X
X
X
X
X
X
X
Reserved -
116 X
X
X
X
X
X
X
X
Horizontal line 2 marker position [little-endian]
0: Top to 1,080: Bottom
0
117 0
0
0
0
0
0
0
X
118 X
X
X
X
X
X
X
X
Horizontal line 2 marker thickness (size) [little-endian]
0: Invisible to 1,080: Maximum
0
119 0
0
0
0
0
0
0
X
11A X
X
X
X
X
X
X
X
Vertical line 2 marker position [little-endian]
0: Left to 1,920: Right
0
11B 0
0
0
0
0
0
0
X
11C X
X
X
X
X
X
X
X
Vertical line 2 marker thickness (size) [little-endian]
0: Invisible to 1,920: Maximum
0
11D 0
0
0
0
0
0
0
X
