No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
89/94
Address
7
6
5
4
3
2
1
0
Descriptions Default
11E 0
0
0
0
X
X
X
X
Circle marker color
*as for the configurable color, please refer to color code chart
0
X
X
X
X
Reserved -
11F X
X
X
X
X
X
X
X
Reserved -
120 X
X
X
X
X
X
X
X
Circle marker radius 0
121 0
0
0
0
X
X
X
X
122 X
X
X
X
X
X
X
X
Circle marker thickness (size) 0
123 0
0
0
0
X
X
X
X
124 X
X
X
X
X
X
X
X
Circle marker center position (horizontal) [little-endian]
0: Left to 1,920: Right
960
125 0
0
0
0
X
X
X
X
126 X
X
X
X
X
X
X
X
Circle marker center position (vertical) [little-endian]
0: Top to 1,080: Bottom
540
127 0
0
0
0
X
X
X
X
128 X
Picture mode selection
0: Normal 1: Pseudo
0
X
Normal color mode shadow mask line color
0: Black
1: Overlay graphics pseudo color
0
X
X
X
X
X
X
Reserved -
129 X
X
X
X
Background pseudo color
*as for the configurable color, please refer to color code chart
1
X
X
X
X
Foreground pseudo color
*as for the configurable color, please refer to color code chart
0
12A X
X
X
X
X
X
X
X
Threshold for Pseudo color 48
12B X
X
X
X
X
X
X
X
Slope for pseudo color slope 16
12C -
140
X
X
X
X
X
X
X
X
Reserved -
141 X
X
X
X
X
X
X
Reserved -
X
Color / Monochrome
0: Color 1: Monochrome
0
142 0
X
X
X
X
X
X
X
R-Y gain
Range: 0 to 127
28
143 0
X
X
X
X
X
X
X
B-Y gain
Range: 0 to 127
28
144 X
X
X
X
X
X
X
X
R-Y hue * Two’s compliment
Range: -128 to 127
-12
145 X
X
X
X
X
X
X
X
B-Y hue * Two’s compliment
Range: -128 to 127
-29
146 X
X
X
X
X
X
X
X
Threshold for high brightness chroma suppression 240
146 X
X
X
X
X
X
X
X
slope for high brightness chroma suppression
Range: 0 to 8
1
148 X
X
X
X
Aperture horizontal gain 3
X
X
X
X
Aperture vertical gain 3
149 0
0
0
0
0
0
0
X
Aperture coring 2
14A -
15F
X
X
X
X
X
X
X
X
Reserved -
