7. Connection Procedure
10
The dialog box on the right is
displayed. Click the Yes Button.
11
Check that the CX-Programmer
and the PLC are normally
connected online.
*The icon
is selected
during online connection.
Additional Information
If the CX-Programmer and PLC are not connected online, please check the connection of the
cable. Or, return to step 5 and check the settings that were set in steps 6 to 8 and try to
connect them again.
Additional Information
The dialogs explained in this document may not be displayed depending on the
environmental setting of CX-Programmer.
This document explains the setting procedure when the setting item "Confirm all operations
affecting the PLC" is selected.
24
To Next Page
