Communication protocols
PROGRAMMING MANUAL 214
Revision 1.0
The Host Link Master protocol supports the commands only in single frame.
The following table shows how you can use the Host Link protocol with the
BASIC commands, and for which CPU unit operating mode (RUN, MON or
PROG) the command is valid.
/i
End codes
These are the end codes defined in the HLM_STATUS parameter:
/i
Note
The Host Link protocol supports only C commands. It does not
support FINS.
Header
code
Name BASIC command
required
RUN MON PRG
RR CIO AREA READ HLM_READ Valid Valid Valid
RL LR AREA READ HLM_READ Valid Valid Valid
RH HR AREA READ HLM_READ Valid Valid Valid
RD DM AREA READ HLM_READ Valid Valid Valid
RJ AR AREA READ HLM_READ Valid Valid Valid
RE EM AREA READ HLM_READ Valid Valid Valid
WR CIO AREA WRITE HLM_WRITE Not valid Valid Valid
WL LR AREA WRITE HLM_WRITE Not valid Valid Valid
WH HR AREA WRITE HLM_WRITE Not valid Valid Valid
WD DM AREA WRITE HLM_WRITE Not valid Valid Valid
WJ AR AREA WRITE HLM_WRITE Not valid Valid Valid
WE EM AREA WRITE HLM_WRITE Not valid Valid Valid
SC STATUS CHANGE HLM_COMMAND Valid Valid Valid
TS TEST HLM_COMMAND Valid Valid Valid
MM PC MODEL READ HLM_COMMAND Valid Valid Valid
XZ ABORT
(command only)
HLM_COMMAND Valid Valid Valid
** INITIALIZE
(command only)
HLM_COMMAND Valid Valid Valid
IC Undefined command
(response only)
- Valid Valid Valid
Caution
You must execute the Host Link master commands from one pro-
gram task only to avoid any multi-task timing problems.
Caution
The Host Link master commands provide the tools to exchange
data with the Host Link slave. The user program must contain
proper error handling routines to deal with communication failure
and perform retries if necessary.
End code Description Probable cause Solution
$00 Normal
completion
No problem exists. N/A
$01 Not executable
in RUN mode
The command that was sent can-
not be executed when the PC is
in RUN mode.
Check the relation
between the com-
mand and the PC
mode.
$13 FCS error The FCS is wrong. Influence from noise,
transfer the command
again.
Header
code
Name BASIC command
required
RUN MON PRG
