3 Electrical Installation
10 I67E-EN V1000 Quick Start Guide
Wiring Specification
Main Circuit
Use the fuses and line filters listed up in the table below when wiring the main circuit. Make
sure not to exceed the given tightening torque values.
Tightening Torque Values
Tighten the main circuit terminals using the torque values provided by the table below.
Model
VZA*
<1> For UL compliance a different fuse type has to be used. For details refer to the instruction manual.
EMC Filter Type
Main
Fuse
(Ferraz)
Recom.
Motor
cable
[mm²]
Main Circuit Terminal Sizes
Rasmi Schaffner
R/L1,S/L2,T/L3,
U/T1,V/T2,W/T3,
- , +1, +2
B1, B2 GND
B0P1
A1000-FIV1010-RE A1000-FIV1010-SE
TRS5R 1.5 M3.5 M3.5 M3.5
B0P2 TRS10R 1.5 M3.5 M3.5 M3.5
B0P4 TRS20R 1.5 M3.5 M3.5 M3.5
B0P7
A1000-FIV1020-RE A1000-FIV1020-SE
TRS35R 2.5 M4 M4 M4
B1P5 TRS50R 4 M4 M4 M4
B2P2 A1000-FIV1030-RE A1000-FIV1030-SE TRS60R 4 M4 M4 M4
B4P0 under development
20P1
A1000-FIV20010-RE A1000-FIV20010-SE
TRS5R 1.5 M3.5 M3.5 M3.5
20P2 TRS5R 1.5 M3.5 M3.5 M3.5
20P4 TRS10R 1.5 M3.5 M3.5 M3.5
20P7 TRS15R 1.5 M3.5 M3.5 M3.5
21P5
A1000-FIV2020-RE A1000-FIV2020-SE
TRS25R 2.5 M4 M4 M4
22P2 TRS35R 4 M4 M4 M4
24P0 A1000-FIV2030-RE A1000-FIV2030-SE TRS60R 4 M4 M4 M4
25P5
A1000-FIV2060-RE A1000-FIV2050-SE
A6T70
<1>
6M4M4M5
27P5
A6T100
<1>
10 M4 M4 M5
2011
A1000-FIV2100-RE -
A6T150
<1>
16 M6 M5 M6
2015
A6T200
<1>
25 M8 M5 M6
40P2
A1000-FIV30005-RE A1000-FIV30005-SE
TRS2.5R 2.5 M4 M4 M4
40P4 TRS5R 2.5 M4 M4 M4
40P7
A1000-FIV3010-RE A1000-FIV3010-SE
TRS10R 2.5 M4 M4 M4
41P5 TRS20R 2.5 M4 M4 M4
42P2 TRS20R 2.5 M4 M4 M4
43P0 TRS20R 2.5 M4 M4 M4
44P0 A1000-FIV3020-RE A1000-FIV3020-SE TRS30R 4 M4 M4 M4
45P5
A1000-FIV3030-RE A1000-FIV3030-SE
A6T50
<1>
4M4M4M5
47P5
A6T60
<1>
6M4M4M5
4011
A1000-FIV3050-RE -
A6T70
<1>
10 M5 M5 M5
4015
A6T80
<1>
10 M5 M5 M6
Terminal Size M3.5 M4 M5 M6 M8
Tightening Torque [Nm] 0.8 to 1.0 1.2 to 1.5 2.0 to 2.5 4.0 to 5.0 9.0 to 11.0
