Omron V600 Series Operation Manual

4-3SectionBasic Operations
60
Run Mode In the RUN Mode, “RUN,” is always displayed and key inputs are not accepted.
There are two switch positions for the RUN Mode, and operation is the same at
both settings.
RUN
RUN
RUN
or
If the mode switch is set to monitor , “MONIT OR” is displayed. When this is dis -
played, only the RESET , DA TA, ADRS, and JOB Keys can be accepted.
RESET
Initial display
ADRS DATA
JOB
a00d00
All key operations can be
accepted
Address can be set
Data can be specified Job specification head
number can be set
a
_
d00 a00d_ HEAD 1
4-3-2 Job Specification (JOB)
This enables setting of the head number and page number for data reading, writ -
ing and testing in the MONITOR Mode.
Operation Procedure The following is an example specifying R/W Head 1 and Page 2 (DC memory
area addresses 0200 to 02FF).
(Changing MONIT OR Mode)
JOB
SET
INC INC
SET
MONITOR
HEAD 1
PAGE 00
PAGE 02
a00d00
(1)
(2)
(3)
(4)
*
Key Assignments in
Monitor Display

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
