Omron V600 Series Operation Manual

4-4SectionData Read and Write Operations
64
Data read by the read operation contains the job specification head and page
numbers. If the start address is not set, the data in address 00 is read.
1, 2, 3... 1. When the READ Key is pressed, “RD” (read operation) appears on the dis -
play,
and the data in the specified address is shown at the right end of the
display. If the READ Key is pressed again, the address is incremented, and
the next data can be read.
Note If no R/W Head is connected, if the DC is not in the communications
range, or if a communication error occurs, an error code is displayed
(see page 97). When this happens, use the horizontal cursor keys to
display the error message.
2. Use the INC/DEC Key to increment or decrement the address, and then
press the READ Key to read the data. To read data from an address of a
different page, start the procedure from the job specification.
Note 1. If
the INC/DEC Key is pressed, and the address exceeds the 00 to FF range:
Page 2
00
FF
00
FF
Page 2
INC
DEC
2. If the address is FF when the INC Key is pressed, the setting returns to
address 00 of the same page.
3. If the address is 00 when the DEC Key is pressed, the setting moves to
address FF of the same page.

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
