Omron V680-CA5D01-V2

157
RFID System
User’s Manual
SECTION 5
V680 Commands
SECTION 5
Communications
 Setting Procedure
Always use the following procedure to set operation conditions.
1. Clear the operation conditions.
Command: SE20*[CR]
Response SE0000*[CR]
2. Set the command string to execute.
Channel 1 Command String (Reads 10H bytes starting from address 0010H from channel 1 with an RA communications
designation.)
Command: SE00C1RDRAH100100010*[CR]
Response SE0000*[CR]
Channel 2 Command String (No Setting)
Command: SE00C2XX*[CR] Note: For the V680-CA5D01-V2, this would produce a format error (end code: 14).
Response SE0000*[CR]
With the V680-CA5D02-V2, always set a command string even if there is no execution command to be executed.
If execution commands are not set for both channel 1 and channel 2, outputs and conditions will not be set.
For the V680-CA5D01-V2, set an execution command only for channel 1.
3. Set the conditions.
OUT1 Output Condition (Turn ON output OUT1 for 100 ms if the 2 bytes of data from 0000 bytes of the data read from
channel 1 is greater than 1234.)
Command: SE00S101>=00000212340100*[CR]
Response SE0000*[CR]
OUT2 Output Condition (Turn ON output OUT2 for 100 ms for any error for channel 1.)
Command: SE00S201ER000000000100*[CR]
Response SE0000*[CR]
OUT3 Output Condition (No Setting)
Command: SE00S3XX*[CR]
Note: OUT3 cannot be set in Two Output Mode. An execution condition error (end code: 15) would occur.
Response SE0000*[CR]
OUT4 Output Condition (No Setting)
Command: SE00S4XX*[CR]
Note: OUT4 cannot be set in Two Output Mode. An execution condition error (end code: 15) would occur.
Response SE0000*[CR]
4. Set the output destination.
Channel 1 Execution Command Output Setting (Always output the execution command for channel 1 from RS-232C.)
Command: SE00U101AL*[CR]
Response SE0000*[CR]
Channel 2 Execution Command Output Setting (No Setting)
Command: SE00U2XX*[CR] Note: For the V680-CA5D01-V2, this would produce a format error (end code: 14).
Response SE0000*[CR]
With the V680-CA5D02-V2, always set a command string for both channel 1 and channel 2 even if there is no execution
command to be executed.
