59
RFID System
User’s Manual
SECTION 3
Switch Settings
SECTION 3
Preparations for Communications
Default Settings
Name
Default
setting
Description Reference
SW1 Controller number upper digit (0 to 9) 0 Controller No. 00
p. 60
SW2 Controller number lower digit (0 to 9) 0
SW3, pin 1 SW enable switch OFF DIP Switches enabled
p. 61
SW3, pin 2 Reserved by system. OFF (Not used)
SW3, pin 3 Baud rate setting 1 OFF Baud rate: 9600 bps
SW3, pin 4 Baud rate setting 2 OFF
SW3, pin 5 Data length OFF Data length: 7 bits
SW3, pin 6 Parity 1 OFF Parity: Even
SW3, pin 7 Parity 2 OFF
SW3, pin 8 Stop bit length OFF Stop bits: 2
SW3, pin 9 Communications protocol OFF 1:1
SW3, pin 10 Command system OFF V680 commands
SW4, pin 1 Test Mode switch setting 1 OFF Distance level measurement
p. 62
SW4, pin 2 Test Mode switch setting 2 OFF
SW4, pin 3 Test Mode switch setting 3 OFF
SW4, pin 4 Antenna specification for test execution OFF Antenna 1
SW4, pin 5 Write verification OFF With write verification
SW4, pin 6 Lower trigger execution setting OFF None
SW4, pin 7 Write protection function disable OFF Enabled
SW4, pin 8
V680-H01 Antenna connection setting
OFF
Connection to antennas other
than the V680-H01
SW4, pin 9 Run Mode setting OFF Command Execution Mode
SW4, pin 10 High-speed Data Transmission setting OFF Normal mode
SW5 Mode switch OFF Run Mode
p. 63
SW6 Terminating resistance OFF No terminating resistance
To Next Page
