61
RFID System
User’s Manual
SECTION 3
Switch Settings
SECTION 3
Preparations for Communications
 DIP Switch Settings (SW3, SW4)
 SW3, Pin 1 (SW Enable Switch)
Note: SW1, SW2, SW3 (pins 3 to 9), and SW4 (pins 5 to 7) are enabled only when the DIP switches
are enabled.
When the internal settings are enabled, the values specified by the TR and SP commands are valid.
The default values will be enabled if values have not been specified using the TR and SP commands.
p. 228, p. 230
 SW3, Pin 2 (Reserved by System)
Do not use this pin. Always set this pin to OFF.
 SW3, Pins 3 and 4 (Baud Rate)
 SW3, Pin 5 (Data Length)
 SW3, Pins 6 and 7 (Parity)
 SW3, Pin 8 (Stop Bit Length)
 SW3, Pin 9 (Communications Protocol)
SW3, pin 1 Description
OFF DIP switch enabled
ON Internal settings enabled
SW3, pin 3 SW3, pin 4 Description
OFF
OFF 9,600 bps
ON 19,200 bps
ON
OFF 38,400 bps
ON 115,200 bps
SW3, pin 5 Description
OFF 7 bits
ON 8 bits
SW3, pin 6 SW3, pin 7 Description
OFF
OFF Even
ON None
ON
OFF Odd
ON Even
SW3, pin 8 Description
OFF 2 bits
ON 1 bit
SW3, pin 9 Description
OFF 1:1
ON 1:N
