SECTION 3
Switch Settings
RFID System
User’s Manual
SECTION 3
Preparations for Communications
SW3, Pin 10 (Command System)
SW4, Pins 1, 2, and 3 (Maintenance Mode Switch Settings)
Maintenance Mode cannot be used when the V680-H01 Antenna is connected.
For details, refer to Maintenance Mode.
p. 66
SW4, Pin 4 (Antenna Specification)
Note: This setting is valid only in Maintenance Mode.
SW4, Pin 5 (Write Verification)
SW4, Pin 6 (Lower Trigger Execution)
Note: This setting is valid only when pin 10 on DIP switch SW3 (command system) is ON.
SW4, Pin 7 (Write Protection Function)
SW3, pin 10 Description
OFF V680 commands
ON V600 commands
SW4,
pin 1
SW4,
pin 2
SW4,
pin 3
Description
OFF
OFF
OFF Distance Level Measurement Mode
ON Tag Communications Test Mode
ON
OFF Speed Level Measurement Mode, Read
ON Speed Level Measurement Mode, Write
ON
OFF OFF Noise Level Measurement Mode
ON
OFF Communications Success Rate Measurement Mode
ON Host Communications Monitor Mode
SW4, pin 4 Description
OFF Antenna 1
ON Antenna 2
SW4, pin 5 Description
OFF With write verification
ON Without write verification
SW4, pin 6 Description
OFF None
ON Enabled (on rising edge)
SW4, pin 7 Description
OFF Enabled
ON Disabled
