RFID System
User's Manual
SECTION 7
Reference Data
SECTION 7
Appendices
143
RF Tag Mounting Precautions
V680-D1KP52MT
Differences in Surrounding Metals(Reference)
Communications ranges are affected by the type of metal in back of or surrounding the RF Tag, as
shown in the following table.
Mutual Interference with RF Tags (Reference)
To prevent malfunctioning due to mutual interference when using more than one RF Tag, leave
sufficient space between them as shown in the following diagram.
Steel SUS Brass Aluminum
V680-D2KF52M 100% 85% to 90% 80% to 85% 80% to 85%
Note: The value for steel around or behind the RF Tag is set to 100%.
25 mm min.
25 mm min.
