SECTION 6
Maintenance and Inspection
SECTION 6
Troubleshooting
75
Maintenance and Inspection
The FL Remote ID must be inspected on a daily or regular basis so that the functions can be used in good
condition. The FL Remote ID consists of semiconductors that last almost indefinitely. The following
malfunctions may, however, result due to the operating environment and conditions.
(1) Element deterioration due to overvoltage or overcurrent.
(2) Element deterioration due to continuous stress caused by high ambient temperature.
(3) Connector contact faults or insulation deterioration due to humidity and dust.
(4) Connector contact faults or element corrosion due to corrosive gas.
■ Inspection Items
No. Item Detail Criteria
Required
equipment
1
Supply voltage fluctua-
tion
(1) Check that the supply voltage fluctuation
at the power supply terminal block is within
the permissible range.
Within supply voltage speci-
fied range
Multimeter
(2) Check that there are no frequent instanta-
neous power failures or radical voltage
fluctuations.
Within permissible voltage
fluctuation range
Power supply
analyzer
2
Ambient environment
Maximum and
minimum ther-
mometer
Hygrometer
(a) Temperature (a) Within the specified range (a) 10 to 55C
(b) Humidity (b) Within the specified range (b) 25% to 85%
(c) Vibration and shock (c) Influence of vibration or impact of
machines
(c) Within the specified
range
(d) Dust (d) Check that the system is free of accumu-
lated dust and foreign particles.
(d) Neither is permitted.
(e) Corrosive gas (e) Check that no metal part of the system is
discolored or corroded.
(e) Neither is permitted.
3
Panel condition
---
(a) Ventilation (a) Check that the system is ventilated prop-
erly with natural ventilation, forced ventila-
tion, or cooling air.
(a) The interior temperature
must be within a range
between 10 and 55C
with proper ventilation.
(b) Damage to packing
for any enclosed
construction
(b) Check that the panel packing is properly
attached with no damage.
(b) The packing must have
no damage.
4
I/O power supply
(a) Voltage fluctuation
(b) Ripple
Check on the I/O terminal block that the volt-
age fluctuation and ripple are within the per-
missible ranges.
Within the specified range
Multimeter
Oscilloscope
5 Mounting condition
(1) Check that each device is securely
mounted.
No loose screws
---
(2) Check that each connector is fully
inserted.
Each connector must be
locked or securely tightened
with screws.
---
(3) Check that no screw of the terminal block
is loose.
No loose screws
---
(4) Check that no wire is broken or nearly bro-
ken.
Must be no wire that is bro-
ken or nearly broken.
---
(5) Check that the distance between the RF
Tag and Antenna is within the specified
range.
Within the specified range
---
6 RF Tag life
Use the RF Tag service life warning function
and manage the number of times the RF Tag
has been written.
Do not allow the specified
maximum number of over-
writes to be exceeded.
---
