SECTION 7
Specifications and Dimensions
RFID System
User's Manual
SECTION 7
Appendices
Specifications and Dimensions
FL Remote ID
 General Specifications
V680-HAM42-FRT
 Communications Specifications
Item Specifications
Communications
protocol
FL-net Remote
Baud rate Automatic switching between 10 Mbps/100 Mbps
Communications
medium
FL-net Cable
Communications
distance
Node to HUB
HUB to HUB
Node to node (one to one connection)
Maximum extendable distance
100 m max.
100 m max.
100 m max.
200 m max.
Note: The node may be either a Master or Slave.
Connection method Switching hub
Node address 01 to 64 (select with switches)
Item Specifications
Supply voltage
(power consumption)
24 VDC +10%/15% (6 W max)
Ambient operating temperature 10 to 55C (with no icing)
Ambient operating humidity 25% to 85% (with no condensation)
Ambient storage temperature 25 to 65C (with no icing)
Ambient storage humidity 25% to 85% (with no condensation)
Insulation resistance
20 M min. (at 500 VDC) between all terminals together (excluding ground terminals) and
ground terminals and between all terminals together (excluding ground terminals) and the
casing
Dielectric strength 1,000 VAC (50/60 Hz) for 1 minute between all power supply terminals together (excluding
ground terminals) and the casing
500 VAC (50/60 Hz) for 1 minute between all terminals together (excluding ground terminals)
and the casing
Vibration resistance 10 to 150 Hz, 0.2-mm double amplitude at 15 m/s
2
in X, Y, and Z directions ten sweeps each
for 8 minutes
Shock resistance 150 m/s
2
in X, Y, and Z directions 3 times each (18 times in total)
Dimensions 65 65 65 (W H D) mm (excluding protruding parts)
Degree of protection Panel-mounting (conforms to IP20)
Material PC/ABS resin
Weight Approx. 150 g
Mounting method
DIN Track
