RFID System
User's Manual
SECTION 3
Parameter Settings for FL Remote Communications
SECTION 3
Preparations for Communications
■ FL Remote M Detail Settings
Click the Details Button in the Link Parameter Settings Dialog Box and select the parameter that you
want to use.
The FL Remote ID does not have a diagnostic function. Parameters cannot be set for this function.
■ Slave Settings Communications Procedure
Click the Slave Settings (E) Button in the FL Remote M Detail Settings Dialog Box and set the
parameters as shown below.
• Slave Connection Settings Select
• Transfer bytes Settings 8 input bytes, 8 output bytes
• Expansion Settings Disable
To Next Page
