Signal Name Function
TEST MODE Test Mode Outputs 1 during operation in test mode when the mode switch is set to 2.
NOISE MODE
Noise Measurement
Mode
Outputs 1 during operation in noise measurement mode when the mode switch is
set to 3.
ID 0-0 to 7 READ DATA Outputs data read from RF Tags when DATA READ is performed. Outputs mea-
sured values when noise measurement is performed.
ID 1-0 to 7
ID 2-0 to 7
ID 3-0 to 7
RUN Operating Outputs 1 when the FL Remote ID is running normally.
BUSY
Executing Outputs 1 when TRG is 1 in trigger mode.
Outputs 1 when INHIBIT
is 1 in auto mode.
NORMAL Normal End Outputs 1 when communications with RF Tags was terminated normally.
ERROR
Error End Outputs 1 when communications with an RF Tag was terminated because of an
error.
By checking the type of ERR_SUB@, the error details can be checked.
ERR_SUB 15 System Error Outputs 1 when FL Remote ID cannot be operated.
ERR_SUB 14 Switch Error Outputs 1 when there is an error in the mode switch setting.
ERR_SUB 13 Command Error Outputs 1 when there is a command error or the command cannot be received.
ERR_SUB 7
RF Tag Service Life
Warning
Outputs 1 when the number or RF Tag overwrites is 100,000 or higher.
ERR_SUB 6 ID System Error 2 Outputs 1 when an RF Tag that is not supported by the FL Remote ID was used.
ERR_SUB 5 ID System Error 1 Outputs 1 when an RF Tag that is not supported by the FL Remote ID was used.
ERR_SUB 4 Mismatch Error Outputs 1 when data was not correctly written to the RF Tag.
ERR_SUB 3
Protection Error Outputs 1 when a command was executed to write data to the write-protected area
of an RF Tag.
ERR_SUB 2
Address Error Outputs 1 when the memory area specified by the command was outside the mem-
ory area of the RF Tag.
ERR_SUB 1
RF Tag Communica-
tions Error
Outputs 1 when the RF Tag was detected but communications could not be ended
normally with the RF Tag in trigger mode.
ERR_SUB 0 RF Tag Missing Error Outputs 1 when a RF Tag could not be detected in trigger mode was used.
