RFID System
User's Manual
SECTION 7
Specifications and Dimensions
SECTION 7
Appendices
87
 Dimensions
V680-HS65-W
V680-HS65-R
Case material ABS resin
Fill resin Epoxy resin
Cable PVC (gray)
Case material ABS resin
Fill resin Epoxy resin
Cable PVC (black)
16.8 dia.
(Unit: mm)
14.5 dia.
Connector
Ferrite core
Insulation cover
37
50
30
16.5 dia.
Coaxial cable, 5.5 dia.,
standard length: 2 m
Operation
indicator
100
90±0.2
90±0.2
100
50
5
5
30
20
10
10
50
Bushing
Four, 4.5 dia.
(Mounting holes)
11
16.8 dia.
(Unit: mm)
14.5 dia.
Connector
Ferrite core
Insulation cover
37
50
16.5 dia.
Coaxial cable, 5.3 dia.,
standard length: 2 m
Bushing
Four, 4.5 dia.
(Mounting holes)
Operation
indicator
100
90±0.2
90±0.2
100
50
5
5
30
20
10
10
50
11
